Safety group
- Max working temperature: 140 °C
- Max working pressure: 10 bar
- Nominal setting pressure (Pn): 3, 6 bar (factory set and sealed)
- Opening overpressure: +10% of Pn
- Reseating pressure: -20% of Pn
- Flow coefficient: K=0,05
- Connections: threaded connections ISO 228-1
- Suitable fluids: water for thermal systems, glycol solutions (max 50%)
- Product codes
- Description
- Documentation
- Accessories
- Spare parts
Product codes
| Item code | Size |
|
|
Setting [bar] | Download the 3D file |
|---|---|---|---|---|---|
| 03D0150003 | G 1/2 M - G 3/4 M | 1 | 20 | 3 | |
| 03D0150006 | G 1/2 M - G 3/4 M | 1 | 20 | 6 |
Description
Safety group for solar pump stations, with safety relief valve, pressure gauge (0–10 bar), expansion vessel connection, connection with O-Ring and locking nut.
